BGD LYNX, EN/LTF-C
BGD LYNX, EN/LTF-C
It’s a wild quest, flying for days away from humanity; pushing your limits, making your own decisions, immersed in nature and working with the elements to slink through the landscape using the power of the air. Whether yours is a lone journey of self-discovery, or one that is silently observed by thousands, the Lynx is for serious athletes and experienced pilots who want to get out there in nature and experience the thrills of adventure flying first-hand.
|Hike And Fly|
Based on the Cure, The Lynx is a streamlined, fully-fledged XC predator. Her refined simplicity makes her faster, lighter, more elegant and competitive while the EN-C certification offers reassurance for experienced pilots. The Lynx has new BGD LITE risers using three strands of 13mm webbing and a performance-optimized speed system. With a new Edelrid Magix pro 8000U comp line set and Porcher Sport’s new laterally reinforced Skytex 32g/m² lightweight cloth, the Lynx is at the leading edge of the game. She is cunning, agile, and will take you to the top of the food chain.
Are you the diehard pilot that is on the hill rain or shine, or do you pick and choose your days? Does your launch look like a putting green or the surface of Mars? One glider can’t be perfect for everything so I designed the BGD LITE collection for pilots who want less weight and improved portability with added performance*.
Designing the highest performing sports class glider in the BGD LITE collection was intriguing, challenging, and rewarding since the improvements are clear. It was originally for the Red Bull X-Alps but quickly evolved into a more versatile glider. I started with the Cure template and reworked it almost from the ground up, simplifying, re-calculating, and adding all the latest materials. All of the BGD range follows this design philosophy and the BGD LITE collection just pushes it a little harder.
*At a small cost in durability.
Cord Cut Billow (CCB)
Cord Cut Billow technology has been developed to improve the form friction, glider stability and overall performance of our paragliders. Two seams run chord-wise across the top panels of the leading edge to accommodate the panel ballooning that happens when the wing is inflated. Up to five centimetres of excess material is created on the sides of an inflated flat panel bending over a wing profile. Cord Cut Billow technology absorbs the material with a 3D panel resulting in fewer ripples and improved rib profile shape and stability.
Leading Edge Mini-Ribs
Situated along the leading edge are reinforced mini-ribs, designed to help produce a rock solid profile while on speed bar.
Porcher Skytex 32
The Lynx utilizes Porcher Sport’s new lighter, stronger Skytex 32g/m² cloth. This cloth is specifically designed for paragliders and is laterally reinforced – paragliders have more tension across the span.
Strong Shark Nose
An ultra aggressive shark nose optimises stability at all speeds. Not all sharks are created equal and BGD’s shark noses are very aggressive, maximizing the effects of the technology.
Minimal line consumption
Optimizing the line layout of a glider is an extremely complex science; we are constantly developing our analytical techniques to improve line design. A wing’s internal structure evolves simultaneously with line layout, and together these design aspects offer better support for reduced line consumption and drag. The Lynx uses new Edelrid Magix pro 8000U lines and has a total line length of just 244m (M).
Snap Locks are lightweight compact attachments that effortlessly connect brakes to the risers with a small focused magnet inside the catch and an internal locking system that holds the handle in every direction except down toward the pilot. This unique design feature means the handles don’t fall off while kiting, packing, or performing manoeuvres. The Snap Lock system solves many of the problems associated with press-studs and magnets.
60 enhanced cells
Cord Cut Billow and new leading edge mini-ribs allow us to lower the number of full cells while gaining the characteristics of a high cell count paraglider. This creates a lighter, cleaner, simpler paraglider.
Light and durable
The Lynx is constructed with an obsessively careful mix of lightweight, robust, and proven materials. From UV resistant colours to carefully chosen cloth angles across the cells, everything is designed to minimise unnecessary weight while maximizing durability.
The LYNX is designed to warn experienced pilots of light-to-moderate turbulence, rather than suddenly completely collapsing when things get really unruly. Bruce’s article in Cross Country magazine, ‘Shifting Our Thinking on Safety’, explains how “A wing that is super stable and almost never collapses can lead to more accidents, because when it does collapse the pilot is not prepared and has little experience of how to deal with the situation”. Any wing will collapse given enough turbulence. A small deflation in medium turbulence is easier to deal with and therefore safer than a big collapse in strong turbulence.
|Linear scaling factor||0.96||1||1.04||1.08|
|Total line length||225||244||264||285||m|
|Number of main lines||3/3/4||A/B/C|
|Flat aspect ratio||6.75|
|Projected aspect ratio||4.87|
|In-flight weight range||60-80||75-95||90-110||105-125||kg|
Certification in progress
|Top surface:||Porcher Skytex 32g/m²|
|Bottom surface:||Porcher Skytex 27g/m²|
|Internal structure:||Porcher Skytex Hard 27-32g/m²|
|Nose reinforcing:||Plastic wire 2,3mm and 2,7mm|
|Risers:||13mm black Kevlar/nylon webbing|
|Pulleys:||Ronstan/Harken P18 pulleys|
|Top lines:||Edelrid Magix Pro 8000U (Unsheathed)|
|Middle lines:||Edelrid Magix Pro 8000U (Unsheathed)|
|Lower lines:||Edelrid Magix Pro 8000U (Unsheathed)|
|Brakes:||Liros DC (Unsheathed)|
- BGD T-shirt
- USB stick with manuals
- BGD stickers
- Stuff sack
- Compression strap
